Sensor 3518E+OV9712 1/4″CMOS
Resolution 1280×720
Pixel 1.0MP
Compression H.264/JPEG
Frame rate Max 25 Frame rate
Bit rate 64Kbps～8Mbps
Min.illumination 0Lux(IR ON)
Lens
Interface type M12，CS
Lens 3.6mm (4mm 6mm are optional)
focusing system Fixed
lamp panel infrared lamp 90 Degrees 36*LED
view distance 20m
Function
Privacy masking support 4
Exposure control Auto
Gain control Auto
White balance Auto
Day & Night function IR - CUT the double filter switch, support color to black
Video Adjustment brightness saturation sharpness and contrast screen mirror
Remote opertation System,stream,storage,user,network mangament
Motion detect Support
Alarm detect Email,CMS alarm
Voice Intercom Support
Local storage NO
POE Optional
ONVIF 2,4
Audio input no
Network
Streams Threee Streams
Network protocols "HTTP,TCP/IP,ICMP.RTSP,RTP,UDP,RTCP,SMTP,
DHCP,DNS,PPPOE"
ethernet 10/100M ethernet，RJ45
Environment
Working Environment -20℃～+55℃
Working Humidity 10%～90%
feature Power DC 12V
Color/Material white metal
Size : 9*7*6cm
| Length | 15 cm |
| Taille caméra | 5.2cm |
| Alimentation Caméra | DC12V-1A |
| Température de fonctionnement DVR | -10°C -- +55°C |
| Température de fonctionnement caméra : | -20℃ ～ +55℃ |
| Résolution : | 1280×720p |
| Capteur d'image | 1/4″CMOS 3518E+OV9712 |
| Vision de nuit | IR - CUT à double filtre |
| Résistance à l'eau | 10% ～ 90% |
| Pixel : | 1.0 MP |
| Compression : | H.264 / JPEG |
| Vitesse image : | Max 25 images/sec |
| Débit : | 64Kbps ～ 8Mbps |
| Minimum illumination : | 0Lux (IR ON) |
| Type lentille : | M1, CS - Lentille 3.6mm - ZOOM fixe |
| Contrôle d'exposition : | 9cm |
| Contrôle de gain : | 5.2cm |
| Balance des blancs : | AUTO |
| Ajustement des images : | AUTO |
| ONVIF : | 78gr |
| Flux : | Triple flux |
| Protocole réseau : | HTTP, TCP/IP, ICMP.RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, PPPOE |
