- DVB-T/T2, MPEG-2,MPEG-4,H.264
SATELLITE INPUT/DEMODULATION
- Connector Type : F Type Female
- Input Frequency : 46 to 862 MHz
- Input impedance : 75 ohms
- Band width : 6M/7M/8M
- ANT Power : 5V<150mA 12V/24V<300mA,
- Demodulation Type : COFDM : QPSK, 16QAM, 64QAM
LCD FEATURES : LCD Type TFT TRANSMISSIVE
- Number of Dots : 480(RGB) x272
- Active area (WxH) : 95.04 x 53.86 mm2
AV output interface
- Connector Type : 3.5 mm Jack
- Video Output : CVBS
- Audio output : Stereo Audio L/R output
AV input interface
- Connector Type : 3.5 mm Jack
- Video input : CVBS
- Audio input : Stereo Audio L/R input
AUDIO/VIDEO PROCESSING
- Video decompression: MPEG-2 MP@HL, MPEG-1 Decoding, MPEG-4 ASP@L5 HD resolution, H.264 MP&HP@L4, HW JPEG
- Resolving rate : PAL-25 frame@720*576, NTSC-30 frame@720*480,
- Signal compatibility : Support conversion for different video formats
- Video Format : 4:3, 16:9, By Pan & Scan and Letter Box conversion
- Audio decompression : MPEG-1 Layer I/II, MPEG-2 Layer I/II
- Audio output mode : Stereo, Mono, R/L
DATA SERVICE PORT
- Connector : USB
- Data protocol : USB2.0 interface
- File management system : NTFS, FAT32, FAT16
- file format : wma, mp3, mp4, avi, jpg, jpeg, bmp, img
- MICROPROCESSOR : Amlogic
- Clock Frequency: 180MHz
- SDRAM Memory 512Mbit
- Power SUPPLY: Li_Ion Battery 8.4V/3000mAh
- Adapter OUTPUT : DC12V/1.5A, INTUPT : 100-240VAC 50/60Hz
- Power consumption: Max. 10W
- Size (W x D x H) : 9.5 x 15.5 x 4.5 (cm3)
